General: This model is meant to be used with its corresponding Github project "SinCosEnc-Conv_EP5101" (https://github.com/PedPEx/SinCosEnc-Conv_EP5101) and simultaniouly mounts the EP5101 to a din-rail and the designed PCB to the Beckhoff EP-module. The goal of this solution is to make a retrofit of an old Maho/Deckel cnc mill more or less plug and play. I designed all of this for the retrofit of a Maho MH400E cnc mill from 1984 with the ancient 11 µA encoder signals. The converter PCB both supports 1V_pp and 11µA_pp encoder signals.

Mounting: heatset inserts (my prefered shop: CNCkitchen ) 4x M2.5x4.0mm and 3x M3x5.7m screws 4x M2.5x6mm and 2x M3x20mm 1x M3x8mm connector 1x M23 socket (female socket, 9Pin(1 big pin), E type - AliExpress Link )

Github project: SinCosEnc-Conv_EP5101
