I lost the reflector from my bike light. The reflector keeps out water, and also ensures that the light points forward while also using the case as a heat-sink.

Printed with Prusa MK3S+

  • Print with the bottom down, using base-plate supports only.
  • Glue a piece of aluminium foil onto the slope as a reflective surface.
  • Glue a piece of acrylic or other clear plastic to use as a lens cover.
  • Use thermal paste to connect the LED PCB to the casing
  • I recommend gluing around the edge a little, to improve water-resistance
