HONEYCOMB ORGANIZERS (13 DIFFERENT VERIONS!)

honeycombstairs.stl

Pen, Pencil, Markers, Stuff Holder for Honeycomb Storage Wall

Honeycomb_HexWall_v2.stl

Honeycomb Storage Wall: Feeler Gauge Holder

This is a quick model to hold a feeler gauge on the [Honeycomb Storage Wall](https://www.printables.com/model/152592-honeycomb-storage-wall) system. It uses an M3 insert backer with a single M3x10 Flathead screw.

This was made to fit specifically [this Feeler gauge. ](https://www.amazon.ca/gp/product/B07B3TQQSV/ref=ppx_yo_dt_b_search_asin_title?ie=UTF8&psc=1)

Magnetic Parallelepiped Blocks

This simple shape can be used create numerous complex and interesting 3D tilings and formations.
The parallelepiped is essentially an octahedron with two tetrahedrons attached to opposite faces, so the tiling is based on the octahedron and tetrahedron pattern found in an octet truss.
The holes are sized for 1/8" cylindrical neodymium magnets, 1/32" long. This size of magnet was selected for cost reasons and to minimize the repulsive forces between the magnets at each tip. This size of magnet is not very strong on its own but suffices when there are multiple faces joined together. If you choose to scale the model larger, you will want to use larger magnets.
The six magnets at the two tips are all inserted with the same polarity, the remaining six magnets around the center are inserted with opposite polarity.
It is a good idea to clean the holes out first with a 1/8" drill bit. CA glues works well.
See here for a video on how to assemble the first and second level cuboctohedron: https://youtu.be/Fpc0BToJeA0
The first level cuboctohedron is made with 12 individual parallelepiped shapes, the second level cuboctohedron is made with 36 individual parallelepiped shapes


Honeycomb vase (Vase No. 12)

These files are for Personal Use Only. If you would like a Commercial License to sell prints made from these designs, please join me on Patreon: https://www.patreon.com/kazitoad

This vase model has a concave bubble texture.

It is specifically designed to be printed in spiral vase mode, printing with one continuous outer wall, to print quickly, without a seam or support.

I suggest using a large nozzle, line width, and layer height. I also suggest printing in spiral vase mode with 6 bottom layers and only 1 outer wall.

Checkout my other models :)

Honeycomb Planter

A 3D Printable Honeycomb Planter.

Print time: 4.5 - 5.5 hours
Size: 9.5 x 6.6 cm (diameter x height)
Weight: 65 grams

If you have questions, please let me know. I am happy to help.

Happy printing

3D printing settings

0.25mm layer height
0.6mm layer width / wall thickness
2 walls - 10% infill
40mm/sec print speed - 120mm/sec travel


hexagonal honeycomb

A generic honeycomb generator that produces hexagonal combs which kind of makes sense. Also they are better suited to be printed on circular printbeds.

The defaults in the scad creates a honeycomb compatible with  the Honeycomb storage wall by RostaP that fits a 230mm circular printbed.




honeycomb plate.stl

Honeycomb Hexagon Honey Dipper.stl

Honeycomb Hex Bin "B"

These are a set of bins I designed specifically for a built-in in my apartment. This one measures 8 inches wide by 5 inches deep by 9 inches (ish) tall (sorry for the units my EU friends).

I've found PETG performs best with this particular model. PLA works, however I usually had a lot of cleanup on the stringing in the hexes afterwards, whereas PETG @ 230c and 150 mm/s worked nearly flawlessly without any stringing.  Please comment your successful settings though as I am still having trouble getting the floor of the bin to print without blistering when using Concentric patterns or the like.

Designed in Tinkercad, the hex pattern is a repeating pattern trimmed on the edges, so re-sizing to whatever dimensions you need should be pretty simple, but message me if you need a particular set of dimensions and I might take a crack at it if I have time. Tinkercad file below to remix with if you want:
https://www.tinkercad.com/things/hZ36bubRkEJ?sharecode=ZK1efOMKQ0vd52pIDA50fgz2jkDBfDEKqysG56LNbEQ

Organizer

Organizer_Gerüst-mk3.stl

Serpentes nTopologus Hexhoneycombus

This “Serpentes nTopologus Hexhoneycombus” is part of a series of three articulating snakes demonstrating various ways that nTopology can be used to design unique topology within complex designs. It incorporates the gyroid TPMS into the body of the snake.

See here for video: https://youtu.be/z7fLPr0367s

These topology snakes use a unique print-in-place ovoid joint designed to maximize available volume and surface area for other design elements.

This joint type is stronger than the interlocking double ring joints used in many articulated designs, so this design is more suitable for use as a fidget or children’s toy.

These snakes are 72cm in length but will print on a 220mm x 220mm build plate.

Like a “ball and socket” joint, the oval-shaped ovoid from one segment is held in place by a similarly shaped socket in the neighbouring segment. Varying the relative dimensions of the ovoid and socket allows for precise control of the movement between each segment. In this design, lateral side-to-side movement is maximized, but rotation and up/down movement is slightly restricted. This more accurately mimics the “tone” and movement patterns of a real snake.

You may get some small adhesions between segments. Simply apply a bit of force to move the joint the first time, and it will be fine after that.


See here for video of similar textured snakes: https://youtu.be/8fIhzqsQP_k

See here for stable downloads of textured snakes:
Bubble Boa: https://thangs.com/mythangs/file/62591
Voronoi Viper: https://thangs.com/mythangs/file/62593
Knurled Nightcrawler: https://thangs.com/mythangs/file/62592


Spring Bulb 2

2 Barely Bulb Square Honeycomb.stl

Honeycomb bee fountain

Honeycomb body.STL

Artsy thing holder

It's a vase, or a pen holder, of a whatever you want to put in it device.
No supports, print in your choice of material. Use it to hold whatever you want of leave it empty and enjoy it presence.
