Tap & Die Hinged Case

This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2078222.

Hinged case for a small tap & die set. Has space for four taps (4, 5, 6 and 8mm), four dies and the T type tap wrench. It doesn't include a space for the die holder (since that's pretty large, and robust enough to sling in a toolbox anyway).

The taps & dies are an inexpensive 10 piece set, for example: http://www.toolstation.com/shop/p10128 https://www.amazon.co.uk/dp/B000LFS22W/ref=cm_sw_r_cp_ep_dp_luMKybRHBXFB3

The base section has some built in support structures for the hinge pins, which need to be cut off. The top section will print upside down without supports.
