Picnic Treasures

This design is a picnic-themed jewelry drawer, perfect for storing small accessories or displaying cute items. The lower section includes a large drawer with a strawberry-shaped handle, and the top features three functional pieces:

๐Ÿงบ Basket: opens with a hinge and has internal storage space. The two parts assemble by press-fit โ€” just apply gentle pressure to snap them together.

๐Ÿฐ Cake: features an integrated hinge, printed as one solid piece that opens and closes smoothly.

๐Ÿธ Frog with strawberry: the frog attaches to the lilypad using a threaded connection, and the strawberry on its head also screws in place. It can be used as a ring holder or small display stand.

๐Ÿ“ Approximate dimensions:

Drawer internal space: 108 mm (width) ร— 20 mm (height) ร— 92 mm (depth)

Total assembled size: 120 mm ร— 75 mm ร— 100 mm

๐Ÿ“น The full assembly and function of each part can be seen in the video on my Instagram (@marigo3d).

UPDATE The basket's hinge has been reinforced and the mechanism has been redesigned. The previous version used a pin-and-hole system. This version works differently: the filament itself acts as the hinge pin, just thread it through and trim. No extra hardware needed. How to assemble the hinge: Print all parts as usual. Cut a short piece of filament (diam: 1.75 mm). Insert it through the hinge barrel until it goes all the way through. Trim the excess flush with the surface.
