I designed this convergent nozzle to fit onto the the famous Jet Engine by Catiav5ftw.

The line on the nozzle is decorative. 🎖️ It is easy to print with standard print settings. ✔️

What is it? A convergent nozzle starts big and gets smaller. Decreasing the cross-sectional area.

Designed by linus3d using fusion360 on thangs.com My website: https://linus3d.de/
