Raspberry Pi 4B Clip-on Fan Mount 30x30

by
lap87
Follow
Follow
Remix Model
lap87
lap87
|
|
Image 1 of 4
Raspberry Pi 4B Clip-on Fan Mount 30x30 - First version to the left, and V1.1 to the right. - 3d model
lap87
lap87
|
|
Image 1 of 4
Raspberry Pi 4B Clip-on Fan Mount 30x30 - First version to the left, and V1.1 to the right. - 3d model
2D
3D
Makes
Raspberry Pi 4B Clip-on Fan Mount 30x30 - First version to the left, and V1.1 to the right. - 3d model
Raspberry Pi 4B Clip-on Fan Mount 30x30 - Heatsinks + fan mounted to RPI4B and working. - 3d model
Raspberry Pi 4B Clip-on Fan Mount 30x30 - V1.1 with pifan from amazon bolted on.  - 3d model
Raspberry Pi 4B Clip-on Fan Mount 30x30 3d model
This model is restricted by licensing terms.

Background: So i built a voron, it uses a raspberry pi 4 as computational power for Klipper. RPI4B gets hot when not cooled actively, thus, i came up with a clip-on design that printed in one piece and let me just smack on a pifan & heatsinks to cool it.

Info: V1.1 may be thick enough to put heat-inserts in the holes, i personally just used long enough screws so i could tighten them with a nut beneath.

Print it however you like, but it was designed to print standing so it has layerlines going across the print for better flexibility. I designed a break-away support piece you need to remove if you want the clips to clear the hdmi/usb ports.
