These are the official game boards for Hextraction, the hackable, 3D-printable board game. I've created two versions - the Basic model uses minimal filament and prints fast. The "Fancy" Gutter version has many useful features, like ball-catching gutters and detachable feet, but consumes considerably more filament and time.

For assembly instructions for a basic board, watch the Hextraction launch video!

I've designed this to be as modular as possible, so you can create boards of any shape and size. If you're sizing a leg for a given slot, you want it to be 25mm taller for every additional slot between it and the end zone.

Fusion 360 source: https://a360.co/3H6op2f

Hextraction is a 3D-printable, modder-friendly board game designed by me, Zack Freedman of Voidstar Lab. In addition to tiles, you'll also need 10mm steel balls or 3/8" slingshot ammo and a game board. To learn the rules and how to get started, watch the Hextraction video!

Hextraction is absolutely free - it's free of charge - all of my models are here on Thangs, commercial use allowed. It's free-form - you can play with any number of opponents, even zero. It's free to modify - you can create your own tiles and configure your own board.

For more information, visit https://playhextraction.com.

Tags:

Community Makes (4)

Thank you for this amazing game. Here it is printed concurrently from my ender pro s1 and k1c. The green parts are ABS and the black is petg. Waiting for kiddo to wake up so we can pick a goal color. Than you again

A lot easier to put together than you might think, little bit of hot glue , a few clips and a edited frame that's 3 parts because I have a smaller build plate. Great creation

Community Makes (4)

Discussions

gabbajoe3 years ago

If you missing a list of the parts to print here: Basic Board 1 x 5-15 Plate 1 x 5-7 Plate 5 x Basic Clips 2 x Basic On-Ramp (missing as single stl but available in "All Hextraction Hexcessories - Don't Print.step") 2 x Universal End Zone 2 x Basic Back Leg Mount 2 x Basic Leg Segment 50mm 2 x Basic Foot Mount Integrated 2 x Universal Foot Integrated

caydenfoyt3 years ago

But also someone made an board plate for this game but made the plates into smaller peices could you figure out how many clips I need for that and it's called hextraction game board for smaller printers it's by link the cat

caydenfoyt3 years ago

Thanks

gabbajoe3 years ago

Fancy Board: 1 x 5-15 Plate 1 x 5-7 Plate 17 x Gutter Segment 3 x Gutter Endcap 2 x Gutter On-Ramp 2 x Gutter Leg Mount 2 x Gutter Leg Start 2 x Gutter Foot Mount Integrated 2 x Universal Foot Integrated 2 x Gutter Leg Segment 50mm (missing as single stl but available in "All Hextraction Hexcessories - Don't Print.step")

matthewmmorrow2 years ago

You forgot the 2x Universal End Zone.

The Gutter Leg Segment 50mm appear to be their own file now.

msolomon07601 year ago

Where is this? i cant find it

guycanadian96511 months ago

Thank you for this amazing game. Here it is printed concurrently from my ender pro s1 and k1c. The green parts are ABS and the black is petg. Waiting for kiddo to wake up so we can pick a goal color. Than you again

PrinterCreality K1C

MaterialPETG

Layer height0.2 mm

Infill density25 %

Lykrast3 years ago

Does any of the pieces require support? Or are they all good to be printed?

meicalnissyen3 years ago

Zack,

sup, love the motivation, If you saw the flow in my project world, you would chuckle, or cry.

I want to get this game, as a packaged unit, off to my kids.

I find alot of effort goes to nifty tile pieces, likely never used as intended, because the game surface element is crap, with little cohesive thought. glueing 47 poorly dimensioned objects together IS NOT the basis for a decent table game.

IE the hex locating grid, gutters, and goal bin were ONE piece, a useful table is had.

hodgeac3 years ago

The heat set insert style feet have a 5.5mm hole for the insert. I've never seen an M3 insert with an OD that big. All of mine are ~4.5mm. These will fit my M4 inserts but the foot itself will need to be drilled out to accept an M4 bolt and I'll have to find a lower profile.

Also completely unrelated but why are there stls for "front leg" segments? The board doesn't have front legs and if you print them and put them in place at the front of the board they aren't quite the right length. Weird.

gabbajoe3 years ago

Hello Zack, can you please let me know what is the difference between this version and the version that you uploaded on May 13, 2023: https://thangs.com/designer/ZackFreedman/3d-model/Hextraction%20Game%20Boards-856439 Also you missed 2 part to export as single stl's see my lists. Any how thank you for this nice game! Cheers, gabbajoe

brettkob3 years ago

Any advice on printing the 5 by 15 grid on an Ender V2, 235mm by 235mm? I can't seem to get that portion to fit in the slicer. Looks like the file is like 235.4 or something like that. I am going to print multiple 5by7 for now and just glue them together.

DomPerignon31 year ago

For anyone wondering, some designers have remixed the Hextraction board, making it easier to assemble and adding cool features. Here is a board designed by Inauble for which I wrote full assembly instructions: https://makerworld.com/fr/models/477165#profileId-388193

pazzocavalo3 years ago

Took some cajoling to get my ender 3 v2 to print something as wide as the build plate, but I eventually got tommi.paakko's 5-8 plate to work: https://thangs.com/designer/tommi.paakko/3d-model/Hextraction%205-8%20Plate-858676

bencham3 years ago

Someone on printables has adapted the beta board for this

pazzocavalo3 years ago

I'm in the same boat. Pity, as I was really excited to print this! Maybe the grid needs to be separated into 4 squarish sections rather than two that are the full width of the game board
