Description

These are the official game boards for Hextraction, the hackable, 3D-printable board game. I've created two versions - the Basic model uses minimal filament and prints fast. The "Fancy" Gutter version has many useful features, like ball-catching gutters and detachable feet, but consumes considerably more filament and time.

For assembly instructions for a basic board, watch the Hextraction launch video!

I've designed this to be as modular as possible, so you can create boards of any shape and size. If you're sizing a leg for a given slot, you want it to be 25mm taller for every additional slot between it and the end zone.

Fusion 360 source: https://a360.co/3H6op2f

Hextraction is a 3D-printable, modder-friendly board game designed by me, Zack Freedman of Voidstar Lab. In addition to tiles, you'll also need 10mm steel balls or 3/8" slingshot ammo and a game board. To learn the rules and how to get started, watch the Hextraction video!

Hextraction is absolutely free - it's free of charge - all of my models are here on Thangs, commercial use allowed. It's free-form - you can play with any number of opponents, even zero. It's free to modify - you can create your own tiles and configure your own board.

For more information, visit https://playhextraction.com.

Tags:

Discussions

gabbajoe3 years ago

If you missing a list of the parts to print here: Basic Board 1 x 5-15 Plate 1 x 5-7 Plate 5 x Basic Clips 2 x Basic On-Ramp (missing as single stl but available in "All Hextraction Hexcessories - Don't Print.step") 2 x Universal End Zone 2 x Basic Back Leg Mount 2 x Basic Leg Segment 50mm 2 x Basic Foot Mount Integrated 2 x Universal Foot Integrated

parsingphase3 years ago

Not all heroes wear capes.

DooBiiE3 years ago

Thanks for the list,

I just downloaded today & it has the on ramp in STL. So that would mean its ok to print from the download?

Just need to fit the 5-15 plate one my ender 3. but people seem to have remixed it in the comments

Looking forward to printing this :D

cybermax523 years ago

Keep being awesome!

hbgmobile3 years ago

Great Work!

gabbajoe3 years ago

Fancy Board: 1 x 5-15 Plate 1 x 5-7 Plate 17 x Gutter Segment 3 x Gutter Endcap 2 x Gutter On-Ramp 2 x Gutter Leg Mount 2 x Gutter Leg Start 2 x Gutter Foot Mount Integrated 2 x Universal Foot Integrated 2 x Gutter Leg Segment 50mm (missing as single stl but available in "All Hextraction Hexcessories - Don't Print.step")

JayPats3 years ago

Thank you!

fov3teastrd3 years ago

Off-Ramp seems to be missing anyone?

trvlmike2 years ago

Why was is this so hard to figure out what to print and how to put it together? Even with the video, he goes through all the steps so darn fast that it's hard to make sense of it all.

KAPI Studio2 years ago

i can't fit the 1 x 5-15 Plate on my ender 3 v2, does anyone have smaller sections?

recordt32 years ago

Check out this remix. https://www.printables.com/model/528431-hextraction-board-for-small-build-plates-148x153

Melon_wolf3 years ago

has the tolerances on this been extremely unforgiving for anyone else? im gunna move to the heat-set stuff instead because i cant get any of the integrated threads to work, and all of the tiles that snap together are extremely tight, i cant get them back apart when i snap them together.

MaBu3 years ago

I had the same issue. The printed parts didn't fit. Because I am new to 3d-printing, I tried scaling the models (tiles @97%) and other silly things. Then I read up on flow calibration. So I recalibrated the e-steps on my extruder, printed single wall calibration cubes and adjusted my flowrate and lastly the horizontal expansion after in my slicer. Here is a comprehensive guide I followed parts of: https://the3dprinterbee.com/3d-printer-calibration/ Now everything fits perfectly.

scottmroberts793 years ago

After I changed my layer height to .12 the threaded parts printed perfectly.

moosef3 years ago

I was able to print the threaded parts, but have to ensure absolutely no support touches them and the threads are aligned with the Z axis to be as clean as possible. The grid seems to be pretty nicely sized and if you are having issues, it might be because you have elephant footing on the first few layers, causing the tolerances to be off?

revoman4 months ago

I scaled the Gutter Foot Mount Integrated to 102%, then careful moved the Universal Foot in and out of the threads a little at a time until it was fully seated. Seemed to work well after that, and it glued to the leg just fine.

Melon_wolf3 years ago

yea, ive decided just to do the basic board with heat sets dont have to deal with tolerances then and i just wont snap together tiles that store snapped together lol

Michael P3 years ago

The tolerances for the integrated threads are very tight. I haven't been able to successfully screw them together yet, even using xy compensation in the slicer.

NomAnor3 years ago

Printing the screw hasn't worked for me neither. But all the parts in the basic set should not be a snap fit because they all get glued together.

moosef3 years ago

The 5-15 plate does not fit when flat on a 220mmx220mm standard plate size. Could it be split into two pieces like the 5-7 in size to print flat on smaller printers?

Zammster3 years ago

I took a shot at making a smaller board because the larger 5-15 doesn't fit on my build plate either. This isn't tested yet, but should work? https://thangs.com/designer/nzambo/3d-model/Hextraction%205-5%20Plate-857242

lavellenott1 year ago

The problem with changing the size of one thing is, you have to change the size of everything from now on to make them fit.

emoryfesel3 years ago

thanks unknifto, file works when rotated 45 degrees

unknifto3 years ago

I made this for a 235x235 bed. not sure it helps you much :( https://thangs.com/mythangs/file/879881

moosef3 years ago

Thanks, looks like this should work, and require 3x those and 1x 5-7 to equal a board. Edit: I printed one and it nests with the 5-7 so should be good to go!
