Paneldue V2 5 inch display enclosure

by
WalterSKW
Follow
Follow
Remix Model
Paneldue V2 5 inch display enclosure 3d model
Paneldue V2 5 inch display enclosure 3d model
2D
3D
Makes
Be the first to upload a Make
This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2494892.

This is an enclosure for a Duet Paneldue 5" V2 display based on Davids design. Meant to be mounted on a 2020-type profile. Backpanel can be mounted upside down. Top and bottom have ventilation holes. Cabling goes through the backpanel. Slot for SD card, USB connector is accessible, 2 holes in the front for reset and erase buttons. Screws are all 3mm self tapping.

I made it in PETG and of course with my preferred 0,6mm nozzled Volcano ;) Layers : Frontpanel : 0,4mm and 0,2mm for the first 2mm on the display side (use 2 profiles in S3D) Backpanel : 0,4mm

No support needed.
