Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4693851.
This is a simple housing to hold a 4 in 1 DC power meter & a 50A/75mV shunt like this one: https://smile.amazon.com/gp/product/B08BCD5J81/ The meter opening is 45mm x 85mm.
I am using it to monitor the input power for the laser module on my Sainsmart LE5040 laser engraver. It is attached to the T-slot frame by using the shunt's M5 mounting screws and t-nuts.
The meter model I used can be found here: https://grabcad.com/library/energy-meter-1 The shunt model I used can be found here: https://grabcad.com/library/shunt-4
