I wanted a handle for my printer bed but was disappointed that all of the options that I found could cause bed leveling problems.

This handle does not touch the springs and instead grips on the shape of the y axis plate.

Each handle also needs a clip to ensure that it does not come off. Line up the bump on the clip with the cut in the handle piece.

There are left and right handles with the option for bed up and down arrows on the handle or without and just blank.

I made the tolerances as tight as I could and the handles seem to be solid for me and don't move around when attached. Can loosen slightly over time but does not affect functionality.

All my models are free, however, my Paypal is http://paypal.me/Stu142 if you wish to buy me a coffee or help fund the failed prototypes of this model. Thanks!
