Assorted Tool Tray, Gridfinity 2x4 base

by
Shayne the bald Squatch
Follow
Follow
Remix Model
2D
3D
Makes
Assorted Tool Tray, Gridfinity 2x4 base 3d model
Assorted Tool Tray, Gridfinity 2x4 base 3d model
Assorted Tool Tray, Gridfinity 2x4 base 3d model
Assorted Tool Tray, Gridfinity 2x4 base 3d model
Assorted Tool Tray, Gridfinity 2x4 base 3d model

This is a tray I doodled for holding all of the usual tools for working on my 2020 based Hobby CNC systems, Laser etcher, 3D printer, etc. It's based on a 2x4 Gridfinity foot print. I added 10mm magnet holes for variety ( I had a bunch). Socket holes on the left fit most 1/4" square drive sockets and Hex bits. Parts tray in the center. Then L wrenches and hex driver holes on the right, as well as a spot for a mini adjustable wrench, and pair of nippers. All holes are intended to fit the tools loosely. I don't like having to wrestle the tray for a tool while I'm holding something in place.
