XYZ Axis Tool

by
Royceirving
Follow
Follow
Remix Model
R
Royceirving
|
Image 1 of 2
XYZ Axis Tool 3d model
R
Royceirving
|
Image 1 of 2
XYZ Axis Tool 3d model
2D
3D
Makes
XYZ Axis Tool 3d model
XYZ Axis Tool 3d model

I got this idea from my robotics class where the professor was demonstrating changes in orientation of a frame from rotations higher in the robot. He used a tool much like this one and I figured I could design and print one that can be taken apart and put into a backpack when class is done.

I would recommend printing the vector pieces at 99 to 98% scaling. While designing the peg and hole mechanism, I left no margin of error making it pretty hard to insert and remove the pieces from the origin.


4 Likes10 DownloadsJanuary 30, 2023
