Simplicity TV Mount Clamp

by
FierceDeityLink
Follow
Follow
Remix Model
Simplicity TV Mount Clamp 3d model
Simplicity TV Mount Clamp 3d model
2D
3D
Makes
Be the first to upload a Make
This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4657320.

Made this to replace a missing plastic piece on an old TV mount from Best Buy. The piece is marked as [05] in the diagram and clamps on the metal tubes. I used a 1/4 in.-20 x 3/4 in. Hex Button Head Stainless Steel Socket Cap Screw (SKU # 753396) and a zinc nut (SKU # 655414) from Home Depot. The nut is a tight fit, and I used a vise to fit it in.

I only replaced one set of clamps. I would recommend testing the TV mount with a dummy weight like a sandbag if you're unsure about this part. Use at your own risk.

Tags: SANUS SYSTEMS Milestone AV Simplicity SLF3 6903-002006
