Low-Profile Sliding Right Angle Jig

by
DrDflo
Follow
Follow
Remix Model
Social
DrDflo
DrDflo
|
|
Image 1 of 3
Low-Profile Sliding Right Angle Jig - Sliding right angle jig allows for the stock material to be held square to the work table. The long slots allow for the clamp to be adjusted such that the stock material is pressed up against the low-profile clamps (eft) - 3d model
DrDflo
DrDflo
|
|
Image 1 of 3
Low-Profile Sliding Right Angle Jig - Sliding right angle jig allows for the stock material to be held square to the work table. The long slots allow for the clamp to be adjusted such that the stock material is pressed up against the low-profile clamps (eft) - 3d model
2D
3D
Makes
Low-Profile Sliding Right Angle Jig - Sliding right angle jig allows for the stock material to be held square to the work table. The long slots allow for the clamp to be adjusted such that the stock material is pressed up against the low-profile clamps (eft) - 3d model
Low-Profile Sliding Right Angle Jig - Sliding clamp is 1/4" thick and can be used for wasteboards with a hole spacing of 10 or 25mm spacing - 3d model
Low-Profile Sliding Right Angle Jig 3d model
This model is restricted by licensing terms.
View license.

This jig is designed to be used with the ultra low-profile clamp. Before the bolts are tightened, the jig can be slid to force the stock material up against the face of the low profile clamps. This makes the most out of the small 1.5mm travel of the ultra low-profile clamps.

This jig is for use with CNC routers that have wasteboards/tables with M5 threaded inserts, like these: https://amzn.to/3wUoazT or aluminum extrusion with T-nuts. This jig will work for hole spacings of 10, 25, 50mm.

Dimensions: 175mm x 175mm

3D Printing Parameters: 30% Infill

Check out this video see my 3D printed work holding in action: https://youtu.be/cU-LR5Mn9fY
