I searched for an adjustable leg for my TV set of cabinets in the living room. I could buy them for a few cents each per piece, but why not try to print them :)

Notes: Print with 5 perimeters ( it held 130kg of weigt on hydraulic press and then I stopped). Print with support from the plate (bed) only.

I added a 0,4mm clearance between the "Cabinet" part and "Floor" part thread. Print time on my Ender 3, is supposed to be 8h37m but i think it'll take about 9h

I used SuperSlicer if anybody wants to know. Printed at 217°C/65°C(glass hotbed with carborundum)

I will try to model it parametricaly in SolidWorks and add the files in ZIP xhere, if anybody would like to change it around and make it bigger or smaller :)

Fingers crossed for success :)
