Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5009327.
This is a small PI Camera Housing & Mount for a Raspberry Pi Camera Module.
This is the PI Camera used: https://www.amazon.co.uk/gp/product/B07G9VLPZH/ref=ppx_yo_dt_b_asin_title_o01_s00?ie=UTF8&psc=1
1.The housing has ribbon cable apertures on all four sides to allow for change in orientation or ribbon pass through.
2.The parts were designed primarily for 3030 extrusion but cannot see why they cannot be used on a 2020 extrusion. TBC.
3.Includes a under and over mount extrusion bracket and two sizes of pivot mounting bracket.
Hardware required:
2 x M3 Heat sets 4 x M2 x 10mm long Hex bolts 1 x M5 x 10mm Hex Bolt 1 x Tee Nut to suit the extrusion.
Printed in AMZ3D Black PLA.
