E3D Heatsink 40mm fan assembly (model3)

by
WalterSKW
Follow
Follow
Remix Model
E3D Heatsink 40mm fan assembly (model3) 3d model
E3D Heatsink 40mm fan assembly (model3) 3d model
2D
3D
Makes
Be the first to upload a Make
This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2192067.

This is an improved version of this thing I modified the air channel from the fan to the heatsink. It is a bit wider on the left and more then a bit on the right. The asymetrical setup is done as I want it to fit between the heatsink (of course) and this BLTouch support. The original version of the shroud works fine, but I wanted to reduce the resistance in the airchannel through the heatsink while still keeping the flex for easy removal/installation and keeping the Volcano completely accessible for nozzle changes. The holes for the screws are made to cut M3 thread in it or to use self-cutting plastic screws. Of course you can use a 3mm drill ....

Works out perfectly :). I've printed it in Polycarbonate (see pictures) and it has enough flex to be easily removed and enough bite and support to stay nicely in place.

Print settings used : 0,6mm nozzle, 0,32mm layers, support needed (but not that much) I've printed it in ABS @240°C with bed @110°C and PC @310°C with bed @125°C
